Laveuse à haute pression
| Max flow | Max pressure | Pump type | Moteur | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 11.3 | 3.0 | 193 | 2800 | DAA-3025A | 6.5HP/196CC |
Feature: 5 Tips, QD nozzle; ID 6.4*8m plastic hose; trigger gun with 20 inch lance; 10″ pneumatic wheel; detergent injections
| Max flow | Max pressure | Pump type | Moteur | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 12.6 | 3.3 | 206 | 3000 | DBC-1507A | 6.5HP/196CC |
Feature: 5 Tips, QD nozzle; ID 8*10m steel braided hose; trigger gun with 20 inch lance; 10″ pneumatic wheel; detergent injections
| Max flow | Max pressure | Pump type | Moteur | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 12.6 | 3.3 | 206 | 3000 | DBC-1507A | 6.5HP/196CC |
Feature: 5 Tips, QD nozzle; ID 8*10m steel braided hose; trigger gun with 20 inch lance; 10″ pneumatic wheel; detergent injections
| Max flow | Max pressure | Pump type | Moteur | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 12.6 | 3.3 | 206 | 3000 | DBC-1507A | 6.5HP/196CC |
Feature: 5 Tips, QD nozzle; ID 8*10m steel braided hose; trigger gun with 20 inch lance; 12″ pneumatic wheel; detergent injections
| Max flow | Max pressure | Pump type | Moteur | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 17 | 4.5 | 248 | 3600 | DBC-1510A | 13HP/390CC |
Feature: 418cc Diesel; 5 Tips ,QD nozzle; ID8*10m steel braided hose; trigger gun with 20inch lance; 10″wheel; detergent injections
| Max flow | Max pressure | Pump type | Power | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 17 | 4.5 | 248 | 3600 | DBC-1510A | 13HP/390CC |
Feature: 5 Tips, QD nozzle; ID 8*10m plastic hose; trigger gun with 20 inch lance; 13″ pneumatic wheel; detergent injections
| Max flow | Max pressure | Pump type | Moteur | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 17 | 4.5 | 248 | 3600 | DBC-1510A | 13HP/390CC |
Feature: 418cc Diesel; 5 Tips ,QD nozzle; ID8*10m steel braided hose; trigger gun with 20inch lance; 10″wheel; detergent injections
| Max flow | Max pressure | Pump type | Moteur | ||
|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Gasoline/Petrol |
| 17 | 4.5 | 248 | 3600 | DBC-1510A | 13HP/390CC |
Feature: 418cc Diesel; 5 Tips ,QD nozzle; ID8*10m steel braided hose; trigger gun with 20inch lance 10″wheel; detergent injections
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 10.4 | 2.2 | 110 | 1600 | DBC-1507C | 2.2KW | 70*48*50 | 45 |
Feature: 2.2KW aluminum cage,single phase, 220V/50HZ, 2 pole, 2880rpm, 5tips QD nozzle, ID8*10M steel braided hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 12.7 | 3.3 | 120 | 1740 | DBC-15085C | 3KW | 70*48*50 | 50 |
Feature: 3KW aluminum cage, single phase, 220V/50HZ, 2 pole, 2880rpm, 5tips QD nozzle, ID8*10M steel braided hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 10.7 | 2.8 | 150 | 2200 | DBC-1507C | 3KW | 71*42.5*47.5 | 55 |
Feature: 3KW aluminum cage, single phase, 220V/50HZ, 2 pole, 2880rpm, 5tips QD nozzle, ID7.14*10M plastic hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 9.2 | 2.5 | 150 | 2200 | DBC-1512C | 3KW | 71*42.5*47.5 | 55 |
Feature: 3KW aluminum cage, single phase, 220V/50HZ ,4 pole, 1450rpm, 5tips QD nozzle, ID7.14*10M plastic hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 9.22 | 2.5 | 150 | 2200 | DBC-1512C | 3KW | 71*42.5*47.5 | 55 |
Feature: 3KW aluminum cage, three phase, 380V/50HZ ,4 pole, 1450rpm, 5tips QD nozzle, ID7.14*10M plastic hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 10.7 | 2.8 | 186 | 2700 | DBC-1514C | 4KW | 71*42.5*47.5 | 62 |
Feature: 4KW aluminum cage, three phase, 380V/50HZ, 4 pole, 1450rpm, 5tips QD nozzle, ID8*10M steel braided hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 13.8 | 3.7 | 206 | 3000 | DBC-1509C | 5.5KW | 85*49*54 | 77 |
Feature: 5.5KW aluminum cage, three phase, 380V/50HZ, 2 pole, 2900rpm, 5tips QD nozzle, ID8*10M steel braided hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 13.3 | 3.5 | 206 | 3000 | DBD-1812C | 5.5KW | 85*49*54 | 79 |
Feature: 5.5KW aluminum cage, three phase, 380V/50HZ, 4 pole 1450rpm, 5tips QD nozzle, ID8*10M steel braided hose, trigger gun with 20inch lance, detergent injections.
| Max flow | Max pressure | Pump type | Power | Package size | G.W. | ||
|---|---|---|---|---|---|---|---|
| LPM | GPM | BAR | PSI | Axial Pump | Electric Motor | LxWxH(CM) | KGS |
| 15.5 | 4.1 | 248 | 3600 | DBD-1814C | 7.5KW | 85*49*54 | 82 |
Feature: 7.5KW aluminum cage, three phase, 380V/50HZ, 4 pole, 1450rpm, 5tips QD nozzle, ID8*10M steel braided hose, trigger gun with 20inch lance, detergent injections.
Application
Maintenance
| Chaque utilisation | First month or 20 hours | Every 3 months or 50 hours | Every 6 months or 100 hours | Every year or 300 hours | ||
|---|---|---|---|---|---|---|
| Engine oil | Check level | √ | ||||
| Change | √ | √ | ||||
| Air cleaner | Check | √ | ||||
| Nettoyer | √(1) | |||||
| Replace | √☆ | |||||
| Sediment Cup | √ | |||||
| Spark plug | Check-Clean | √ | ||||
| Replace | √ | |||||
| Spark arrester(optional parts) | Nettoyer | √ | ||||
| Idle speed | Check-Adjust | √(2) | ||||
| Valve clearance | Check-Adjust | √(2) | ||||
| Fuel tank and strainer | Nettoyer | √(2) | ||||
| Combustion chamber | Nettoyer | After every 300 Hrs. (2) | ||||
| Fuel line | Check | Every 2 years (Replace if necessary) (2) | ||||
☆ Replace the paper element type only.
(1) Entretien plus fréquent en cas d'utilisation dans des zones poussiéreuses.
(2)L'entretien de ces éléments doit être confié à votre revendeur, à moins que vous ne disposiez des outils adéquats et que vous soyez mécanicien. Reportez-vous au manuel pour connaître les procédures d'entretien.
Effectué tous les mois indiqués ou toutes les heures de fonctionnement, au premier des deux termes échus.
